➩ Key Features
High-Efficiency Power System – Equipped with a high-performance internal combustion engine, operating at 1500RPM for stable and reliable power output.
Superior Fuel Economy – Optimized thermal efficiency, reducing fuel consumption and operational expenses.
Eco-Friendly & Low Emissions – Produces lower emissions and noise levels, meeting national and international environmental standards.
Intelligent Control System – Advanced control module for remote monitoring and automated operation, enhancing maintenance convenience.
Compact & Versatile Design – Space-saving structure suitable for various applications, including factories, commercial buildings, data centers, and off-grid power supply.
➩ Technical Specifications
| (I)Natural gasgenerator set parameters |
| Type | NPG100 |
| Continuous power(standard state)kW | 100 |
| Rated frequency(Hz) | 50 |
| Rated voltage(V) | 400 |
| Rated current(A) | 180 |
| Rated speed (rpm) | 1500 |
| Gas consumption (kJ/kW ·h) | 10286±5% |
| Generation efficiency | 0.35 |
| Oil consumption(g/kW ·h) | ≤1.5 |
| Weight (t) | 2.4 |
| Overall dimension (Length×Width×Height)m | 3.0×1.2×1.7 |
| (II)Gas engine parameters |
| Model Type | 6138G-1 |
| Type | Four-stroke,water cooling,air natural suction,natural gas cylinder
direct injection mixing,spark plug ignition,electric control |
| Rated power(standard state)kW | 110 |
| Cylinder type | L-shaped,straight |
| Number of cylinders | 6 |
| Bore (mm) | 138 |
| Stroke (mm) | 150 |
| Displacement(L) | 13.5 |
| Rated speed (rpm) | 1500 |
| Cooling mode | Forced water cooling |
| Lubrication mode | Pressure lubrication and splash lubrication |
| Intake mode | Natural aspiration (separate air and natural gas intake) |
| Starting mode | Electric starting |
| (III)Engine |
| Type | lFC6283-4-100 |
| Rated capacity (kVA) | 125 |
| Rated voltage(V) | 400 |
| Rated current (A) | 180 |
| Power factor | 0.8 lagging |
| Rated speed (rpm) | 1500 |
| Connection mode | Three-phase four-wire |
| Excitation mode | Brushless self-encouragement |
| Insulation class | F Grade |
| Protection mode | IP23 |
➩ Applications
Industrial manufacturing and backup power
Data centers, hospitals, and commercial buildings
Biogas power generation and oilfield gas applications
Off-grid power supply for remote areas or microgrids
