➩ Product Advantages
1. High Power Generation Efficiency
With an impressive power generation efficiency of 40% to 42%, this generator set maximizes energy utilization by achieving a total energy efficiency of over 80% when combining power generation, flue gas, and hot water recovery. The unit's low gas consumption rate of≤8990kJ/kW·h ensures cost-effective operation, making it an ideal choice for businesses seeking both efficiency and sustainability.
2. Safe and Reliable
Designed with advanced safety mechanisms, the generator eliminates risks of backfire, discharge issues, and explosions, ensuring stable and secure operation. With an exhaust temperature of approximately 450°C, it offers excellent heat resistance, while high-quality, durable components enhance reliability and longevity, minimizing maintenance requirements.
3. Clean Emission & Eco-Friendly Operation
Engineered for environmental sustainability, this generator set meets strict emission standards with NOx emissions ≤200mg/m³, sulfur dioxide emissions ≤10mg/m³, and particulate emissions ≤10mg/m³. Its low-emission design reduces environmental impact, making it a greener choice for power generation.
4. Excellent Sudden Load Performance
Featuring a fast dynamic response system, the generator quickly adapts to power fluctuations and sudden load changes without compromising stability. This ensures continuous, smooth power supply, making it ideal for industries requiring uninterrupted and reliable energy delivery.
5. Superior High-Altitude Adaptability
Designed for versatile operation, this generator maintains consistent performance even in high-altitude environments ranging from 1,000 to 3,000 meters. Its robust engineering minimizes efficiency losses, making it a reliable power solution for mountainous and remote regions.
➩ Technical Parameters
| Gas generator set parameters |
| Rated power(kW) | 3000-4000 |
| Rated speed (rpm) | 1000 |
| Rated voltage(V) | 10500 |
| Frequency (Hz) | 50 |
| Power factor | 0.8 lagging |
| Number of phase and connection | Three phases,star shape |
| Generation efficiency | About 42% |
| Gas consumption (kJ/kW ·h) | 8570～9000±5% |
| Oil consumption(g/kW ·h) | ≤0.6 |
| Noise (dBA) | 102～110 |
| Continuous power | 80%-90% |
| Weight (kg) | 58000 |
| Overall dimension (Length×Width×Height)m | 8.5×2.4×3.4 |
| Cooling mode | Closed double circuit forced cooling or open cooling |
| Overhaul period | 60000 h |
| Design life | more than 25 years |
| 1.Engine technical parameters |
| Engine type | 16V280G |
| Rated speed (rpm) | 1000 |
| Number of cylinders | 16 |
| Cylinder type | V-Shape |
| Bore (mm) | 280 |
| Stroke (mm) | 290 |
| Displacement(L) | 286 |
| Exhaust temperature(℃) | ≤530 |
| Gas inlet pressure (kPa) | 300-400 |
| Lubricating oil temperature(C) | ≥70 |
| Start Method | Compressed air starting |
| 2.Generator parameters |
| Rated capacity(power)kVA | 3750-5000 |
| Rated voltage(V) | 10500 |
| Connection mode | Three-phases |
| Excitation mode | Brushless self-encouragement |
| Insulation class | H Grade |
| Protection mode | IP23 |
➩ Product Uses
1.Prime Power Supply
Industrial Facilities: Used as the main power source in manufacturing plants, oil refineries, and chemical plants.
2.Standby/Emergency Power
Hospitals & Healthcare Facilities: Ensures critical medical equipment operates during outages.
Data Centers: Prevents data loss by providing uninterrupted power.
Commercial Buildings: Keeps essential services running in hotels, malls, and office buildings.
3.Peak Shaving & Load Management
Industrial & Commercial Sectors: Reduces electricity costs by running generators during peak demand to avoid high utility rates.
Grid Support: Used by utilities to manage power loads and prevent grid overloads.
4.Renewable Energy Integration
Biogas Power Plants: Converts landfill gas, wastewater treatment plant gas, or agricultural biogas into electricity.
Hybrid Systems: Works alongside solar or wind power to ensure stable energy supply when renewable sources fluctuate.
5.Oil & Gas Industry
Onshore & Offshore Drilling Sites: Provides power for drilling rigs, extraction equipment, and worker camps.
Flare Gas Utilization: Converts waste gas into electricity, reducing environmental impact.
6.Agriculture & Farming
Greenhouses: Supplies power for lighting, heating, and ventilation.
Livestock Farms: Runs automated feeding systems and climate control.
7.Construction & Infrastructure
Temporary Power for Construction Sites: Supports equipment like cranes, pumps, and lighting.
Infrastructure Projects: Used in road building, railway maintenance, and tunnel excavation.
➩ FAQ:
1: Are you a trading company or a manufacturer?
We are a trading company as well as a manufacturer.
2: What kinds of gas generator sets do you produce?
It covers all kinds of gas produced in agriculture and industry, including natural gas, hydrogen, biogas, CBM, COG, semi-coke gas, as well as related gas purification equipment.
3: What's your warranty?
For all our products we offer one year warranty.
4: What is your delivery time?
Normally within 40 days, it depends on the configuration and quantity, please confirm with us before ordering.
5: What is your available port of shipment?
Normally Shanghai port, other ports are available according to customers' requirements.
