➩ Technical Parameters
| Gas generator set parameters |
| Rated power(kW) | 500-600 | 800-1000 |
| Rated speed (rpm) | 1000 |
| Rated voltage(V) | 400 | 400/10500 |
| Frequency(Hz) | 50 |
| Power factor | 0.8 lagging |
| Number of phase and connection | Three-phase four-wire |
| Generation efficiency | 40% | 41% |
| Gas consumption (kJ/kW ·h) | 9000±5% | 8780±5% |
| Oil consumption(g/kW ·h) | ≤0.6 |
| Noise (dBA) | 80 |
| Continuous power | 80%-90% |
| Weight (kg) | 11800 | 19500 |
| Overall dimension(Length×Width×Height)m | 5.0×1.8×2.5 | 6.0×2.5×2.5 |
| Cooling mode | water cooling |
| Overhaul period | 20000 h |
| Design life | 20 years |
| 1.Engine technical parameters |
| Engine type | 12V190G-1 | 12V190G-2 |
| Rated speed (rpm) | 1000 |
| Number of cylinders | 12 |
| Cylinder type | V-Shape |
| Bore (mm) | 190 | 190 |
| Stroke (mm) | 210 | 230 |
| Displacement(L) | 72 | 79 |
| Exhaust temperature(℃) | ≤530 |
| Gas inlet pressure (kPa) | 300 |
| Lubricating oil temperature(C) | ≥70 |
| Start Method | Electric starting |
| 2.Generator parameters |
| Rated capacity(power)kVA | 625-750 | 1000-1250 |
| Rated voltage(V) | 400 | 400/10500 |
| Connection mode | Three-phase four-wire |
| Excitation mode | Brushless self-excitation,digital voltage regulator,thyristor |
| Insulation class | F Grade |
| Protection mode | IP23 |
➩ Effectiveness And Durability
1.High efficiency power generation:
Power Generation Efficiency: 16V190 is designed to optimize energy efficiency and is able to provide up to 41% power generation efficiency. Through efficient combustion and energy conversion processes, it is able to provide a powerful power output with relatively low fuel consumption, ensuring the continuous and stable operation of the equipment.
Power Stability: Due to the stable operating principle of this model, it is able to operate efficiently in the range of 80%-90% of continuous power, maintaining a consistent output even under prolonged loads and avoiding damage caused by overloading.
2. Digital Ignition Technology:
The 16V190 utilizes an advanced digital ignition system, which provides a high degree of precision and stability, reducing the need for maintenance due to malfunction of traditional ignition systems. Its increased durability extends engine life and reduces the frequency and cost of routine maintenance.
3. Optimized design:
This model is designed with excellent durability, taking into full consideration the environmental and load demands of long-term use. Even under complex or harsh environmental conditions, it can still maintain a long service cycle and efficient operational performance.
4. Remote electric control system:
16V190 is equipped with remote electric control system, which can monitor the generator's operation status in real time. Through remote monitoring, abnormalities can be detected in time for adjustment or maintenance, which helps to minimize the occurrence of malfunctions and further extend the service life of the equipment.
5. Anti-fatigue design: For long-time working conditions, 16V190 adopts anti-fatigue design, which reduces the damage caused by long-time high load operation and ensures its reliability and durability under various working conditions.
➩ Application Scenarios
1.Industrial power generation:
Suitable for factories and industrial production lines: 16V190 generator can provide stable power support in industrial environments, especially suitable for power supply of large-scale production equipment such as factories and workshops. With its efficient power generation efficiency and continuous power output, it can meet the stable power demand of large-scale equipment. In industrial machinery and equipment that require constant high loads, the 16V190 can provide a reliable source of power to ensure stable equipment operation and reduce downtime.
2.Building and construction sites:
In remote areas or construction sites where there is no stable power supply, 16V190 can provide stable power for concrete mixers, power tools, cranes and other equipment. Its durability and high efficiency are especially suitable for long-time operation, ensuring that construction projects are completed on time.
3. Temporary power solution:
At the construction site, the 16V190 can be used as a temporary power solution to provide the necessary power support, avoiding reliance on the traditional power grid and ensuring uninterrupted power supply during the construction process.
4.Emergency Backup Power Supply:
16V190 is widely used in emergency backup power systems for critical facilities such as hospitals, shopping malls and data centers. It is able to start automatically when the main power supply goes out, ensuring the normal operation of critical equipment and systems and preventing losses caused by power outages.
