➩ Product Applications
Our 200kW 1500RPM Natural Gas Generator Set is suitable for a wide range of applications, including:
Industrial & Manufacturing – Continuous power supply for factories, production lines, and industrial plants.
Commercial & Public Facilities – Reliable backup power for shopping malls, hospitals, office buildings, and data centers.
Renewable Energy & Biogas Utilization – Converts biogas from wastewater treatment plants, landfills, and farms into electricity.
Oil & Gas Fields – Utilizes shale gas and associated petroleum gas for efficient on-site power generation.
Remote Areas & Off-Grid Locations – Independent power supply for mines, rural communities, and islands.
➩ Technical Advantages
High-Efficiency Engine & Power System
1500RPM high-speed operation ensures greater power density and quick response.
Optimized combustion efficiency enhances fuel utilization and reduces energy waste.
Compatible with Combined Heat and Power (CHP) systems, maximizing overall energy efficiency.
Eco-Friendly & Low-Emission Technology
Advanced air-fuel ratio control ensures complete combustion, minimizing NOx and CO₂ emissions.
Low-noise design, with optional soundproof enclosures for noise-sensitive environments.
Self-diagnostic function detects and alerts potential issues, improving maintenance efficiency.
Parallel operation capability for synchronizing multiple generator units to meet higher power demands.
➩ Technical Specifications
| (I)Natural gasgenerator set parameters |
| Type | NPG100 |
| Continuous power(standard state)kW | 100 |
| Rated frequency(Hz) | 50 |
| Rated voltage(V) | 400 |
| Rated current(A) | 180 |
| Rated speed (rpm) | 1500 |
| Gas consumption (kJ/kW ·h) | 10286±5% |
| Generation efficiency | 0.35 |
| Oil consumption(g/kW ·h) | ≤1.5 |
| Weight (t) | 2.4 |
| Overall dimension (Length×Width×Height)m | 3.0×1.2×1.7 |
| (II)Gas engine parameters |
| Model Type | 6138G-1 |
| Type | Four-stroke,water cooling,air natural suction,natural gas cylinder
direct injection mixing,spark plug ignition,electric control |
| Rated power(standard state)kW | 110 |
| Cylinder type | L-shaped,straight |
| Number of cylinders | 6 |
| Bore (mm) | 138 |
| Stroke (mm) | 150 |
| Displacement(L) | 13.5 |
| Rated speed (rpm) | 1500 |
| Cooling mode | Forced water cooling |
| Lubrication mode | Pressure lubrication and splash lubrication |
| Intake mode | Natural aspiration (separate air and natural gas intake) |
| Starting mode | Electric starting |
| (III)Engine |
| Type | lFC6283-4-100 |
| Rated capacity (kVA) | 125 |
| Rated voltage(V) | 400 |
| Rated current (A) | 180 |
| Power factor | 0.8 lagging |
| Rated speed (rpm) | 1500 |
| Connection mode | Three-phase four-wire |
| Excitation mode | Brushless self-encouragement |
| Insulation class | F Grade |
| Protection mode | IP23 |
➩ After-Sales Service
We provide comprehensive after-sales support to ensure the long-term reliability and efficiency of your generator set:
Warranty Service – Standard 1-2 year warranty, with extended service plans available.
24/7 Technical Support – Remote diagnostics, troubleshooting, and real-time monitoring assistance.
Spare Parts Supply – Genuine parts with fast delivery to ensure minimal downtime.
Routine & Preventive Maintenance – Regular inspections, oil changes, and component replacements to optimize performance.
On-Site Training & Consultation – Operator training and technical guidance for seamless operation.
Need support? Contact us anytime!
➩ FAQ
1. What are the main benefits of using a natural gas generator?
Lower fuel costs compared to diesel generators.
Reduced carbon emissions and compliance with environmental regulations.
Stable power output with high thermal efficiency.
Longer engine lifespan due to cleaner combustion.
2. What fuel types can this generator use?
The generator primarily runs on natural gas.
3. How efficient is this generator?
It features high thermal efficiency and optimized fuel combustion, ensuring minimal gas consumption and maximum power output.
4. Can this generator be used in a parallel system?
Yes! Our generator can be synchronized with multiple units for higher power demand and redundancy.
5. What is the noise level of this generator?
The generator operates at low noise levels, with an optional soundproof enclosure available for noise-sensitive locations.
6. Does the generator have an automatic control system?
Yes! It is equipped with a PLC-based digital control panel for remote monitoring, automated start/stop, and system diagnostics.
7. What is the warranty period?
We offer a standard 1-2 year warranty, with extended service options upon request.
8. How often does this generator need maintenance?
Daily checks: Monitor gas supply, oil levels, and system status.
Every 500 hours: Change oil, inspect spark plugs, and replace air filters.
Every 1,000 hours: Comprehensive engine inspection and fine-tuning.
Annually: Full system inspection and potential component replacements.
9. What are the installation requirements for this generator?
The generator requires a stable natural gas supply, proper ventilation, and a suitable installation area. We provide installation guidance and technical support for smooth setup.
10. How can I request a quote or technical consultation?
Contact us today for pricing, specifications, and customized solutions!
